Ultra High Pressure Hydraulic Hose

Short Description:

Product Descriptions The reinforcement of the ultra high pressure hydraulic hose  is high strength steel wire winding layer with special treatment. Four layer design,  two of them is high strength steel wire braid. 4 times safety factor. Outside jacket is polyurethane material to provide the maximum abrasion resistance. Small fluid resistance, small volume expansion, good chemical corrosion resistance, light weight small outside diameter, which greatly facilitates the use of various types of ...


Product Detail

Product Tags

Product Descriptions

The reinforcement of the ultra high pressure hydraulic hose  is high strength steel wire winding layer with special treatment. Four layer design,  two of them is high strength steel wire braid. 4 times safety factor. Outside jacket is polyurethane material to provide the maximum abrasion resistance. Small fluid resistance, small volume expansion, good chemical corrosion resistance, light weight small outside diameter, which greatly facilitates the use of various types of hydraulic tools. All hydraulic hoses conduct over-pressure testing before they leave the factory. High capacity of bearing pressure, the maximum working pressure is up to 400MPa, matched with hydraulic bolt tensioners, hydraulic nuts, ultra high pressure hydraulic cylinders, ultra high pressure hydraulic nut splitters and also suitable for other 150MPa pressure hydraulic tools.

Technical Parameters

Model

Max. Working Pressure

(MPa)

Hose Length

(m)

Thread

(in)

KET-CYG-150-2M

150

2

G1/4” external thread

KET-CYG-150-4M

150

4

KET-CYG-150-6M

150

6

G1/4” external thread

KET-CYG-150-12M

150

12

G1/4” external thread

KET-CYG-200-2M

200

2

G1/4” external thread

KET-CYG-200-4M

200

4

G1/4” external thread

KET-CYG-200-6M

200

6

G1/4” external thread

KET-CYG-200-12M

200

12

G1/4” external thread

KET-CYG-300-2M

300

2

G1/4” external thread

KET-CYG-300-4M

300

4

G1/4” external thread

KET-CYG-300-6M

300

6

G1/4” external thread

KET-CYG-300-12M

300

12

G1/4” external thread

2         1
